DC Tape Clips
DC Tape Clips
| DC Tape Clips | |||||
|---|---|---|---|---|---|
| Conductor Size mm | Conductor Material | L mm | W mm | H mm | |
| 25 x 3 | Gum metal | 50 | 20 | 10 | |
| 25 x 6 | Gum metal | 50 | 20 | 12 | |
| 31 x 3 | Gum metal | 60 | 20 | 10 | |
| 31 x 6 | Gum metal | 60 | 20 | 12 | |
| 38 x 3 | Gum metal | 64 | 20 | 10 | |
| 38 x 6 | Gum metal | 64 | 20 | 12 | |
| 40 x 4 | Gum metal | ||||
| 40 x 6 | Gum metal | ||||
| 50 x 3 | Gum metal | 80 | 20 | ||
| 50 x 6 | Gum metal | 80 | 20 | ||
| 25 x 3 | Aluminium | 56 | 20 | 14 | |
| 25 x 6 | Aluminium | 58 | 20 | 18 | |
| 31 x 3 | Aluminium | ||||
| 31 x 6 | Aluminium | ||||
| 38 x 3 | Aluminium | ||||
| 38 x 6 | Aluminium | ||||
| 40 x 4 | Aluminium | ||||
| 40 x 6 | Aluminium | ||||
| 50 x 3 | Aluminium | ||||
| 50 x 6 | Aluminium | 91 | 20 | 19 | |
| 25 x 3 | Brass | 77 | 27 | 25 | |
| 25 x 6 | Brass | ||||
| 31 x 3 | Brass | ||||
| 31 x 6 | Brass | ||||
| 38 x 3 | Brass | ||||
| 38 x 6 | Brass | ||||
| 40 x 4 | Brass | ||||
| 40 x 6 | Brass | ||||
| 50 x 3 | Brass | ||||
| 50 x 6 | Brass | ||||
| 25 x 3 | Copper | ||||
| 31 x 3 | Copper | ||||
| 50 x 6 | Copper | ||||
DC tape clips, also known as direct current tape clips or cable clips, are small metal or plastic clips designed to secure and fasten DC (direct current) electrical cables or tapes to a fixed surface. They are commonly used in electrical installations, both indoors and outdoors, to ensure proper cable management and prevent cables from sagging or hanging loosely.
Key features and uses of DC tape clips include:
- Securing DC Cables: DC tape clips are used to hold DC power cables or electrical tapes securely in place. They prevent cables from moving or becoming tangled, which can help maintain a neat and organized electrical system.
- Preventing Damage: By securing DC cables, the clips help prevent potential damage that may be caused by cable movement or exposure to environmental factors like wind, rain, or vibrations.
- Easy Installation: DC tape clips are generally easy to install and can be attached to various surfaces, such as walls, ceilings, or support structures, using screws, nails, or adhesive backing.
- Material: DC tape clips are often made of metal, such as Steel or Copper, or durable plastic materials, which provide strength and resistance to environmental factors.
- Application: DC tape clips are used in a variety of applications, including automotive electrical systems, solar power installations, battery banks, marine electrical systems, and other DC power distribution setups.
It’s important to choose the appropriate size and type of DC tape clips based on the diameter and type of cables or tapes being secured. Using the right size ensures a snug fit and effective cable management. Additionally, when installing DC tape clips, care should be taken not to damage the cable insulation or conductors, as this could compromise the electrical integrity of the system.
