Square Tape Clamps
Square Tape Clamps
| Bare Copper Tapes | ||||
|---|---|---|---|---|
| Conductor size mm | L mm | W mm | H mm | Unit Weight kg |
| 25 X 3 | 50 | 50 | 13 | 0.15 |
| 25 X 6 | 50 | 50 | 20 | 0.25 |
| 31 X 3 | 60 | 60 | 14 | 0.22 |
| 38 X 6 | 71 | 71 | 22 | 0.56 |
| 50 x 3 | 80 | 80 | 16 | 0.5 |
| 50 x 6 | 79 | 79 | 22 | 0.52 |
| Material: Gunmetal | ||||
| Lead Covered Copper Tape | ||||
|---|---|---|---|---|
| Conductor size mm | L mm | W mm | H mm | Unit Weight kg |
| 25 x 3 | 70 | 70 | 25 | 0.86 |
| Material: Phosphor Bronze | ||||
| Bare Aluminium Tape | ||||
|---|---|---|---|---|
| Conductor size mm | L mm | W mm | H mm | Unit Weight kg |
| 25 x 3 | 50 | 50 | 13 | 0.07 |
| Material: Aluminium | ||||
Square tape clamps, also known as flat tape clamps or rectangular tape clamps, are specialized electrical components used to secure and establish electrical connections with flat or rectangular conductors, such as Copper or Aluminium tapes. They are commonly used in electrical installations, grounding systems, and bonding applications.
Key features and uses of square tape clamps include:
- Design: Square tape clamps are designed to accommodate flat or rectangular conductors, providing a secure and reliable electrical connection.
- Material: Square tape clamps are typically made of high-conductivity materials, such as Copper or tinned Copper, to ensure low-resistance connections.
- Versatility: Square tape clamps come in various sizes to accommodate different dimensions of flat conductors. They are suitable for use with Copper or Aluminium tapes in various applications.
- Termination: Square tape clamps often feature holes or slots to allow for easy termination of the flat conductors using screws, bolts, or other fasteners.
- Electrical Bonding: Square tape clamps are used in bonding applications to establish electrical connections between metallic components, such as structural Steel, equipment enclosures, or pipelines, ensuring equal potential and reducing the risk of electrical hazards.
- Grounding Systems: In grounding systems, square tape clamps are used to connect the grounding conductor (grounding tape) to grounding electrodes, such as ground rods or ground plates, establishing a reliable grounding path.
- Lightning Protection: Square tape clamps play a vital role in lightning protection systems, where they are used to connect the lightning protection tape or conductor to air terminals (lightning rods) and down conductors.
- Easy Installation: Square tape clamps are easy to install and facilitate quick connections, making them a popular choice in various electrical and grounding applications.
Square tape clamps are essential for creating secure and low-resistance electrical connections with flat conductors, ensuring the efficiency and safety of electrical and grounding systems. Proper installation, correct sizing, and regular maintenance are crucial to ensure the longevity and effectiveness of the connections.
